Coating Laminated And Color Pvc Coated Steel Coils

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Min. Order: 25 Metric Ton
Delivery Time: 30 Days

Additional Info


Packaging: Seaworthy standard export packing . CARDBOARD SLEEVES, STEEL SHEET WRAPPED OUTSID, FIXED BY STEEL BELT.

Productivity: 300000

Brand: XINGHAN

Transportation: Ocean,Land

Place of Origin: CHINA

Supply Ability: 500000

Certificate: ISO 9001:2008/SGS/BV

Port: TIANJIN,CHINA,QINGDAO


Product Description

Production detail
Galvanized steel is steel that has gone through a chemical process to keep it from corroding.The steel gets coated in layers of zinc oxide because this protective metal does not get rusty as easily.The coating also gives the steel a more durable ,hard to scratch finish that many people find attractive.For countless outdoor,marine,or industrial applications, galvanized steel is an essential fabrication

component.



Exporting Machine And Color Aluzinc coated steel coil

Contents
Prepainted Galvanized-PPGI
Prepainted Galvalume-PPGL
BASE METAL
GALVANIZED
GALVALUME / ALUZINC

STANDARDS
JIS G -3312,ASTM A -755 ,
ASTM A 755M,
EN -10169, IS -14246,G300-G550
WITH SUBSTRATE ASTM A792 M
THICKNESS
0.16~1.20 mm
0.16~1.20 mm
Width
600 TO 1300 mm
600 TO 1300 mm
Coil ID
508 & 610 mm
508 & 610 mm
Coil  OD
1700 mm max
1700 mm max
Coil WT
3 TO 8 MT
3 TO 8 MT Max – With ref. to width of coil
Substrate

Soft, Medium, Hard

Soft, Medium, Hard
Hardness
YS (Mpa)
240 -700
240 -700
Coating Mass
Z 40-275 (Grams / m2)
AZ 50-150 (Grams / m2)


Paint Systems

Primers: Epoxy, PU
Primers: Epoxy, PU
Polyester (RMP/PE)
Polyester (RMP/PE)
Silicon Modified Polyester (SMP)
Silicon Modified Polyester (SMP)
Poly Vinyl Di Flouride (PVDF)
Poly Vinyl Di Flouride (PVDF)
Back Coating: Epoxy, Polyester, PU
Back Coating: Epoxy, Polyester, PU
Coating
20 – 50 Microns
20 – 50 Microns
Thickness
top can 3 coats and back can 2 coats
top can 3 coats and back can 2 coats
Colour
As Per RAL Chart/Customer requirements.
As Per RAL Chart/Customer requirements.
Surface Finishes
Glossy and Matte
Glossy and Matte
Cut to length
200mm-5000mm
200mm-5000mm
Slits
30mm and above
30mm and above
Packing
Sea Worthy Export Packaging
Sea Worthy Export Packaging


Color Coated Coil:

Color coated steel sheet steel coil(PPGI PPGL) has light qualitative, beautiful with good anti-corrosion performance, can direct processing again, color is divided commonly for white, blue, red. It is mainly used in advertising industry, building construction industry, household appliance industry, electric appliance industry, furniture industry and transportation industry. Color coated steel coil uses coating to choose proper resin according to different use environment, if polyester silicon modifies polyester, polyvinyl chloride plastic sol, get together vinylidene chloride to wait. Users can choose according to the purpose.
